Double-acting tie-rod cylinder, Xv 466 - Norgren SM/980/540/F/H/466

Name: Double-acting tie-rod cylinder, Xv 466 - Norgren SM/980/540/F/H/466
Brand: Norgren
SKU: NRG-SM/980/540/F/H/466
Price: 8745.03 EUR
Availability: InStock

Norgren ✓ Original product Brand new

The Norgren SM/980/540/F/H/466 double-acting tie-rod cylinder produces linear motion with compressed air in both directions. The order designation of the SM/980/540/F/H/466 also specifies the dimension Xv = 466. The exact order number SM/980/540/F/H/466 lets you replace an existing cylinder of the same version.

Net

€8,745.03

excl. VAT

Item NRG-SM/980/540/F/H/466

Manufacturer no. SM/980/540/F/H/466

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren SM/980/540/F/H/466 is a double-acting tie-rod cylinder.

Features

Double-acting: the SM/980/540/F/H/466 extends and retracts with compressed air, no return spring is needed.
The dimension Xv = 466 is part of the order designation of the SM/980/540/F/H/466.
Order number SM/980/540/F/H/466 reorders an existing cylinder of the same version on a like-for-like basis.

Applications

Typical tasks for the SM/980/540/F/H/466 are pushing, lifting, clamping and traversing in machines and plants.

Technical data

Manufacturer	Norgren
Order number	SM/980/540/F/H/466
Type	tie-rod cylinder
Function	double-acting
Dimension Xv	466
Medium	compressed air
Customs tariff number	84123100
ECLASS	51010101
Weight	0.1 kg
Hersteller-Nr	SM/980/540/F/H/466
Zolltarifnummer	84123100
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Ausführung	doppeltwirkend
Bauform	Zugstangenzylinder
