Double-acting pneumatic cylinder, magnetic piston, 50 mm bore, 150 mm stroke - Norgren TPVA/8050/M/150
The Norgren TPVA/8050/M/150 double-acting pneumatic cylinder produces linear motion with compressed air in both directions, sized for a 50 mm bore and 150 mm of stroke. Its magnetic piston prepares the TPVA/8050/M/150 for contactless position sensing with cylinder switches. The exact order number TPVA/8050/M/150 lets you replace an existing cylinder of the same version.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren TPVA/8050/M/150 is a double-acting pneumatic cylinder with a 50 mm bore and 150 mm of stroke.
Features
- Double-acting: the TPVA/8050/M/150 extends and retracts with compressed air, no return spring is needed.
- Cylinder switches sense the magnetic piston of the TPVA/8050/M/150 without contact, so the end positions can be monitored.
- The 50 mm bore is encoded in size code 8050 of the TPVA/8050/M/150.
- The stroke of 150 mm is defined in order number TPVA/8050/M/150.
- Order number TPVA/8050/M/150 reorders an existing cylinder of the same version on a like-for-like basis.
Applications
Typical tasks for the TPVA/8050/M/150 are pushing, lifting, clamping and positioning in automation.
Technical data
| Manufacturer | Norgren |
|---|---|
| Order number | TPVA/8050/M/150 |
| Type | pneumatic cylinder |
| Function | double-acting |
| Piston | magnetic piston |
| Bore | 50 mm |
| Stroke | 150 mm |
| Medium | compressed air |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Weight | 0.1 kg |
| Hersteller-Nr | TPVA/8050/M/150 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend, mit Magnetkolben |
| Bauform | Pneumatikzylinder |
| Piston Ø [mm] | 50 |
| Stroke [mm] | 150 |
