Pneumatic cylinder, double-acting, 200 mm bore, 100 mm stroke, magnetic piston - Norgren NA/8200/M/100
For presses, lifting and tilting fixtures, the Norgren double-acting pneumatic cylinder NA/8200/M/100 provides a 200 mm bore and 100 mm stroke. The magnetic piston of the NA/8200/M/100 allows end positions to be sensed with cylinder switches. Compressed air drives the piston of the NA/8200/M/100 in both directions for controlled extend and retract strokes.
Net
excl. VAT
€1,852.62
Item
NRG-NA/8200/M/100
Manufacturer no.
NA/8200/M/100
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pneumatic cylinder from Norgren: the NA/8200/M/100 offers a 200 mm bore and 100 mm stroke.
Benefits
- 200 mm bore: the NA/8200/M/100 converts compressed air into high linear force
- 100 mm stroke on the NA/8200/M/100 for medium travel distances
- Double-acting: the NA/8200/M/100 extends and retracts under air pressure
- Magnetic piston in the NA/8200/M/100 for contactless position sensing with cylinder switches
Applications
Users install the NA/8200/M/100 for presses, lifting and tilting fixtures.
Technical data
| Type | NA/8200/M/100 |
|---|---|
| Manufacturer | Norgren |
| Design | pneumatic cylinder |
| Operating principle | double-acting |
| Bore | 200 mm |
| Stroke | 100 mm |
| Magnetic piston | yes |
| Medium | compressed air |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Weight | 0.1 kg |
| Hersteller-Nr | NA/8200/M/100 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend, mit Magnetkolben |
| Bauform | Pneumatikzylinder |
| Piston Ø [mm] | 200 |
| Stroke [mm] | 100 |
| Function | double-acting |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
