Pneumatic cylinder, double-acting, 200 mm bore, 420 mm stroke, rod extension XV 300 mm - Norgren CA/8200/420/UF/H/300

Name: Pneumatic cylinder, double-acting, 200 mm bore, 420 mm stroke, rod extension XV 300 mm - Norgren CA/8200/420/UF/H/300
Brand: Norgren
SKU: NRG-CA/8200/420/UF/H/300
Price: 2858.57 EUR
Availability: InStock

Norgren ✓ Original product Brand new

With a 200 mm bore and 420 mm stroke, the Norgren double-acting pneumatic cylinder CA/8200/420/UF/H/300 is suited to presses, lifting and tilting fixtures. The piston rod of the CA/8200/420/UF/H/300 is extended by 300 mm to clear attached parts. Compressed air drives the piston of the CA/8200/420/UF/H/300 in both directions for controlled extend and retract strokes.

Net

€2,858.57

excl. VAT

Item NRG-CA/8200/420/UF/H/300

Manufacturer no. CA/8200/420/UF/H/300

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

The Norgren CA/8200/420/UF/H/300 is a double-acting pneumatic cylinder with a 200 mm bore and 420 mm stroke.

Benefits

200 mm bore: the CA/8200/420/UF/H/300 converts compressed air into high linear force
420 mm stroke on the CA/8200/420/UF/H/300 for medium travel distances
Double-acting: the CA/8200/420/UF/H/300 extends and retracts under air pressure
Piston rod extension XV 300 mm on the CA/8200/420/UF/H/300 for attachments that need clearance

Applications

Typical uses of the CA/8200/420/UF/H/300 are presses, lifting and tilting fixtures.

The option code UF is part of the order code CA/8200/420/UF/H/300, so take the complete number from the rating plate when ordering a replacement.

Technical data

Type	CA/8200/420/UF/H/300
Manufacturer	Norgren
Design	pneumatic cylinder
Operating principle	double-acting
Bore	200 mm
Stroke	420 mm
Piston rod extension XV	300 mm
Medium	compressed air
Customs tariff number	84123100
ECLASS	51010101
Weight	0.1 kg
Hersteller-Nr	CA/8200/420/UF/H/300
Zolltarifnummer	84123100
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Ausführung	doppeltwirkend, Kolbenstangenverlängerung XV 300 mm
Bauform	Pneumatikzylinder
Piston Ø [mm]	200
Function	double-acting
