Tie-rod cylinder, double-acting, 160 mm bore, 285 mm stroke, magnetic piston, G 3/4 port - Norgren RA/8160/M/285
With a 160 mm bore and 285 mm stroke, the Norgren double-acting tie-rod cylinder RA/8160/M/285 is suited to presses, lifting and tilting fixtures. The magnetic piston of the RA/8160/M/285 allows end positions to be sensed with cylinder switches. The RA/8160/M/285 operates from 1 to 16 bar and connects via G 3/4 ports.
Net
excl. VAT
€1,334.93
Item
NRG-RA/8160/M/285
Manufacturer no.
RA/8160/M/285
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Tie-rod cylinder from Norgren: the RA/8160/M/285 offers a 160 mm bore and 285 mm stroke.
Benefits
- 160 mm bore: the RA/8160/M/285 converts compressed air into high linear force
- 285 mm stroke on the RA/8160/M/285 for medium travel distances
- Double-acting: the RA/8160/M/285 extends and retracts under air pressure
- Magnetic piston in the RA/8160/M/285 for contactless position sensing with cylinder switches
- Operating pressure 1 to 16 bar and G 3/4 ports on the RA/8160/M/285
- Adjustable end-position cushioning slows the piston of the RA/8160/M/285 before it reaches the end stop
Applications
Users install the RA/8160/M/285 for presses, lifting and tilting fixtures.
Technical data
| Type | RA/8160/M/285 |
|---|---|
| Manufacturer | Norgren |
| Design | tie-rod cylinder |
| Operating principle | double-acting |
| Bore | 160 mm |
| Stroke | 285 mm |
| Magnetic piston | yes |
| Medium | compressed air |
| Operating pressure | 1 to 16 bar |
| Port size | G 3/4 |
| End-position cushioning | adjustable |
| Barrel | anodised aluminium |
| Piston rod | stainless steel, martensitic (1.4021) |
| Piston seal | polyurethane |
| Elastomers | nitrile rubber (NBR) |
| Outer dimensions height x width | 183.5 x 183.5 mm |
| Series | RA/8000/M |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Weight | 0.1 kg |
| Hersteller-Nr | RA/8160/M/285 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend, mit Magnetkolben |
| Bauform | Zugstangenzylinder |
| Seal material | NBR, PU |
| Housing material | Aluminium, anodised |
| Working pressure max. [bar] | 16 |
| Function | double-acting |
| Cushioning | adjustable |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G3/4 |
