Double-acting tie-rod cylinder, 160 mm bore, 1150 mm stroke - Norgren RA/8160/M/1150

With a 160 mm bore and 1150 mm of stroke the Norgren tie-rod cylinder RA/8160/M/1150 is sized for high forces on compressed air.

Benefits

• The 160 mm bore of the RA/8160/M/1150 gives about 201.1 cm² of effective piston area on the cap end as the basis for force sizing.
• 1150 mm of stroke on the RA/8160/M/1150 as a fixed, ordered travel.
• Double-acting: the RA/8160/M/1150 extends and retracts under air pressure, without spring return.
• Tie-rod construction on the RA/8160/M/1150 with a 160 mm bore.

Applications

Typical tasks for the RA/8160/M/1150 are moving and clamping with compressed air in fixtures and machines.
