Double-acting tie-rod cylinder, 160 mm bore, 525 mm stroke - Norgren RA/8160/525

A 160 mm bore and 525 mm of stroke define the Norgren tie-rod cylinder RA/8160/525.

Benefits

• The 160 mm bore of the RA/8160/525 gives about 201.1 cm² of effective piston area on the cap end as the basis for force sizing.
• 525 mm of stroke on the RA/8160/525 as a fixed, ordered travel.
• Double-acting: the RA/8160/525 extends and retracts under air pressure, without spring return.
• Tie-rod construction on the RA/8160/525 with a 160 mm bore.

Applications

The RA/8160/525 suits linear motion and clamping tasks in pneumatics where a large bore is required.
