Double-acting magnetic piston tie-rod cylinder 200 mm bore, 92 mm stroke - Norgren RA/8200/M/92
For heavy linear motion and clamping tasks the Norgren RA/8200/M/92 provides a 200 mm piston bore and a 92 mm stroke. The theoretical force of the RA/8200/M/92 is 18840 N, and being double-acting it extends and retracts under compressed air. The magnetic piston of the RA/8200/M/92 allows position sensing with cylinder switches.
Net
excl. VAT
€1,537.63
Item
NRG-RA/8200/M/92
Manufacturer no.
RA/8200/M/92
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren RA/8200/M/92 is a double-acting magnetic piston tie-rod cylinder with a 200 mm piston bore and a 92 mm stroke.
Benefits
- 200 mm bore: theoretical force 18840 N on the RA/8200/M/92
- 92 mm stroke: the order code of the RA/8200/M/92 fixes this stroke length
- Double-acting: the RA/8200/M/92 extends and retracts under compressed air
- Adjustable end-position cushioning: the piston of the RA/8200/M/92 decelerates into the end position
- Magnetic piston: position sensing on the RA/8200/M/92 with cylinder switches
- G3/4 port: pressure range 1 to 16 bar on the RA/8200/M/92
Applications
The RA/8200/M/92 handles linear motion and clamping tasks in automation and fixture construction.
Technical data
| Manufacturer | Norgren |
|---|---|
| Type | RA/8200/M/92 |
| Design | magnetic piston tie-rod cylinder |
| Operation | double-acting |
| Piston bore | 200 mm |
| Stroke | 92 mm |
| Series | RA/8000/M |
| Medium | compressed air |
| Pressure range | 1 to 16 bar |
| Port | G3/4 |
| Ambient temperature | -10 to 80 °C |
| Cushioning | adjustable end-position cushioning |
| Magnetic piston | yes |
| Theoretical force | 18840 N |
| Barrel | anodised aluminium |
| Elastomers | nitrile rubber (NBR) |
| Piston seal | polyurethane |
| Piston rod | stainless steel, martensitic (1.4021) |
| Customs tariff number | 84123100 |
| ECLASS | 51010101 |
| Weight | 0.1 kg |
| Hersteller-Nr | RA/8200/M/92 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend, Magnetkolben |
| Bauform | Zugstangen-Magnetzylinder |
| Piston Ø [mm] | 200 |
| Seal material | NBR, PU |
| Housing material | Aluminium, anodised |
| Working pressure max. [bar] | 16 |
| Pneumatic connection | G3/4 |
| Temperaturbereich | -10-80 °C |
