ISO 6432 round cylinder, single-acting, 16 mm bore, 50 mm stroke, M5, spring at front cover, magnetic piston - Norgren RM/28016/M/50

With a 16 mm bore the Norgren RM/28016/M/50 produces a theoretical 102 N over 50 mm of stroke.

Benefits in use

• The RM/28016/M/50 follows ISO 6432 and can be swapped for other ISO 6432 cylinders with 16 mm bore.
• The RM/28016/M/50 has a magnetic piston, cylinder switches sense its position over 50 mm of stroke without mechanical contact.
• The RM/28016/M/50 operates from 2 to 10 bar with a 16 mm bore.
• The RM/28016/M/50 is rated for ambient temperatures from -10 to 80 °C.
• The RM/28016/M/50 has a barrel in austenitic stainless steel and a piston rod in austenitic stainless steel.
• On the RM/28016/M/50 elastic end-position buffers soften the impact.

Applications

Typical tasks for the RM/28016/M/50 are assembly, packaging and test stations with low forces, sized for 50 mm of stroke.
