Single-acting profile mini cylinder, bore 50 mm, stroke 80 mm, spring/base end - Norgren PRA/803050/M/80
The Norgren profile mini cylinder PRA/803050/M/80 works with a 50 mm bore and 80 mm stroke and handles stroke and positioning movements. As a single-acting cylinder, the PRA/803050/M/80 needs compressed air on one piston side only, with the spring at the base end. The mounting dimensions of the PRA/803050/M/80 follow ISO 15552.
Net
excl. VAT
€227.31
Item
NRG-PRA/803050/M/80
Manufacturer no.
PRA/803050/M/80
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a 50 mm bore and 80 mm stroke, the Norgren profile mini cylinder PRA/803050/M/80 covers linear drive tasks in compressed air systems. Operating principle of the PRA/803050/M/80: single-acting.
Benefits
- 50 mm bore on the PRA/803050/M/80 as the basis for force calculation
- 80 mm stroke on the PRA/803050/M/80 for the required travel
- Single-acting: the PRA/803050/M/80 saves compressed air because only one side is pressurised
- Mounting dimensions of the PRA/803050/M/80 to ISO 15552, interchangeable with cylinders of the same standard
Applications
In packaging and assembly technology the PRA/803050/M/80 handles positioning, lifting and clamping movements.
Technical data
| Design | Profile mini cylinder |
|---|---|
| Operating principle | single-acting |
| Spring arrangement | spring/base end |
| Bore | 50 mm |
| Stroke | 80 mm |
| Standard | ISO 15552 |
| Medium | Compressed air |
| Norgren part number | PRA/803050/M/80 |
| Weight | 2.2 kg |
| Manufacturer | Norgren |
| Hersteller-Nr | PRA/803050/M/80 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Piston Ø [mm] | 50 |
| Stroke [mm] | 80 |
| Function | single-acting |
| Norm | ISO 15552 |
