Single-acting compact cylinder, bore 32 mm, stroke 20 mm - Norgren RA/191032/M/20

Name: Single-acting compact cylinder, bore 32 mm, stroke 20 mm - Norgren RA/191032/M/20
Brand: Norgren
SKU: NRG-RA/191032/M/20
Price: 117.05 EUR
Availability: InStock

Norgren ✓ Original product Brand new

With a 32 mm bore and 20 mm stroke, the single-acting compact cylinder Norgren RA/191032/M/20 handles linear and clamping movements in fixtures and machines. The single-acting RA/191032/M/20 uses compressed air in one stroke direction.

Net

€117.05

excl. VAT

Item NRG-RA/191032/M/20

Manufacturer no. RA/191032/M/20

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A 32 mm bore and 20 mm stroke define the Norgren RA/191032/M/20, a single-acting compact cylinder.

Benefits

Piston area from the 32 mm bore of the RA/191032/M/20 sets cylinder force together with pressure
Fixed 20 mm stroke on the RA/191032/M/20 for repeatable end positions
Single-acting: the RA/191032/M/20 needs compressed air for one stroke direction only

Applications

Typical tasks for the RA/191032/M/20 are clamping, lifting, ejecting and positioning in fixture construction and assembly technology.

Technical data

Order number	RA/191032/M/20
Design	compact cylinder
Operation	single-acting
Bore	32 mm
Stroke	20 mm
Variant code	M
Medium	Compressed air
Customs tariff number	84123100
ECLASS	51010101
Weight	0.1 kg
Manufacturer	Norgren
Hersteller-Nr	RA/191032/M/20
Zolltarifnummer	84123100
GPSR Herstellerdaten	Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand	New
Artikel-Authentizität	Original product
Ausführung	einfachwirkend
Bauform	Kompaktzylinder
Piston Ø [mm]	32
Stroke [mm]	20
