Pneumatic compact cylinder, 40 mm bore, 400 mm stroke, double-acting - Norgren RA/192040/M/400
The Norgren RA/192040/M/400 is a pneumatic compact cylinder with a 40 mm bore and 400 mm stroke. The RA/192040/M/400 converts compressed air into linear motion and force for motion and clamping tasks. The RA/192040/M/400 is double-acting, extending and retracting are both powered by compressed air.
Net
excl. VAT
€328.88
Item
NRG-RA/192040/M/400
Manufacturer no.
RA/192040/M/400
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With a 40 mm bore and 400 mm stroke, the Norgren RA/192040/M/400 handles linear strokes where a standard cylinder would need too much length.
Benefits
- Piston area of the RA/192040/M/400 is 12.57 cm², giving a theoretical extend force of about 750 N at 6 bar.
- The 400 mm stroke is fixed in the type code RA/192040/M/400, no stroke setting is needed during installation.
- Double-acting design of the RA/192040/M/400: both directions of travel are powered by compressed air.
Applications
Typical tasks for the RA/192040/M/400 are clamping, feeding and ejecting in fixtures and assembly systems.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | RA/192040/M/400 |
| Design | compact cylinder (double-acting) |
| Bore | 40 mm |
| Stroke | 400 mm |
| Version code | M |
| Piston area | 12.57 cm² |
| Medium | Compressed air |
| Weight | 0.1 kg |
| Hersteller-Nr | RA/192040/M/400 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | doppeltwirkend |
| Bauform | Kompaktzylinder |
| Piston Ø [mm] | 40 |
| Stroke [mm] | 400 |
