Air fuse excess flow shut-off valve, G1, air fuse - Norgren T60C8890
The Norgren air fuse T60C8890 shuts off the compressed air line automatically as soon as the flow rises above its trip value after a hose burst, with G1 ports and a flow of 4080 l/min. The T60C8890 resets automatically once the fault is cleared, operating pressure up to 16 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren air fuse T60C8890 shuts off the compressed air line automatically as soon as the flow rises above its trip value after a hose burst, with G1 ports and a flow of 4080 l/min.
Benefits
- Operating pressure 0 to 16 bar at -20 to 80 °C for the T60C8890
- G1 port thread on the T60C8890
- Assists in complying with safety regulations on the T60C8890
- Tamper proof design on the T60C8890
- Low pressure drop in normal operation on the T60C8890
- High corrosion resistance on the T60C8890
Applications
The T60C8890 belongs in supply lines to tools, hoses and machines where a severed hose would otherwise whip uncontrolled.
Technical data
| Manufacturer | Norgren |
|---|---|
| Part number | T60C8890 |
| Product type | Air fuse excess flow shut-off valve |
| Product range | T60 |
| Valve function | 2/2 |
| Port | G1 |
| Flow | 4080 l/min |
| Medium | compressed air |
| Operating pressure | 0 to 16 bar |
| Temperature range | -20 to 80 °C |
| Body material | Aluminium |
| Hex size | 51 mm |
| Shape | straight, in-line |
| RoHS | compliant |
| REACH | SVHC substance not present |
| Customs tariff number | 84814090 |
| Weight | 0.55 kg |
| Hersteller-Nr | T60C8890 |
| Zolltarifnummer | 84814090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Housing material | Aluminium |
| Function | 2/2 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1 |
| Temperaturbereich | -20-80 °C |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
