Double-acting round cylinder, bore 25 mm, stroke 340 mm, Rc1/8 - Norgren RT/57225/M/340

The Norgren round cylinder RT/57225/M/340 is double-acting with a 25 mm bore and 340 mm stroke and delivers a theoretical force of 247 N.

Benefits

• 247 N theoretical force from a 25 mm bore on the RT/57225/M/340
• Fixed 340 mm stroke on the RT/57225/M/340 for repeatable end positions
• Magnetic piston in the RT/57225/M/340 for contactless end position sensing with cylinder switches
• Elastic buffers on the RT/57225/M/340 soften the end-of-stroke impact
• Piston rod of the RT/57225/M/340 in stainless steel (martensitic)
• Operating pressure 1 to 10 bar at -10 to 80 °C for the RT/57225/M/340

Applications

In fixtures, assembly and handling stations the RT/57225/M/340 takes on tasks such as clamping, lifting and ejecting.
