Elbow - AS*2*1FM - SMC AS2211FM-N02-11S
Model: AS22 (1/8, 1/4 Basis, Elbow) Control Type: 1 (Meter-in) Port Size and Tube Size: N02-11 (Port size NPT1/4, Tube size Ø3/8) Option: S (Sealant) Made to Order: None Lock Nut: Standard (Hexagon)
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Where finite adjustment is required to control actuators at very low speeds such handling fragile material or smooth process control the "-FM" series has been designed exclusively to meet this requirement. Effective orifice area has been reduced to 1/10th of standard series, but still retains 10 turns of the adjustment needle, (20 turns on the M5 size). This series comes complete with One-Touch fittings and is available in elbow and universal style construction. Currently available in Metric to suit tube sizes from 3.2mm to 10 mm OD, and thread sizes from M5 to ¼ R(PT)
Technical data
| Weight | 0.1 kg |
|---|---|
| Manufacturer | SMC |
| Hersteller-Nr | AS2211FM-N02-11S |
| Zolltarifnummer | 84813099 |
| GPSR Herstellerdaten | SMC Deutschland GmbH Boschring 13-15 DE-63329 Egelsbach www.smc.eu |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
