Proportional pressure regulator up to 3 bar G1/8 VPPM-6L-L-1-G18-0L3H-A4P-S1 - Festo 575804
Electrically adjustable pressure up to 3 bar: proportional pressure regulator VPPM-6L-L-1-G18-0L3H-A4P-S1 with 4 - 20 mA setpoint. Port G1/8 and weight 0.55 kg. Genuine Festo part 575804.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The proportional pressure regulator VPPM-6L-L-1-G18-0L3H-A4P-S1 sets the output pressure electrically up to 3 bar, specified via a 4 - 20 mA setpoint signal. Pneumatically it is connected via G1/8.
Benefits at a glance
- Actual value feedback to the controller via analogue output 4 - 20 mA
- PNP switching output for limit value signals
Application
The VPPM-6L-L-1-G18-0L3H-A4P-S1 is connected electrically via M12, 8-pin, plug.
Technical data
| Type | VPPM-6L-L-1-G18-0L3H-A4P-S1 |
|---|---|
| Festo part number | 575804 |
| Nominal size, supply | 6 mm |
| Pneumatic connection, port 1 | G1/8 |
| Pressure regulation range up to | 3 bar |
| Signal range analogue input | 4 - 20 mA |
| Signal range analogue output | 4 - 20 mA |
| Switching output | PNP |
| Electrical connection | M12, 8-pin, plug |
| Weight | 0.55 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VPPM-6L-L-1-G18-0L3H-A4P-S1 |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/8 |
| Control range max. [bar] | 3 |
| Series | VPPM |
| Pneumatic connection | G1/8 |
