VP60 series proportional flow and directional control valve, G1/4, IO-Link - Norgren VP6010LJLL1MB200
Controls pressure or flow steplessly from the control signal. The VP60 series proportional flow and directional control valve Norgren VP6010LJLL1MB200 is suitable for compressed air and seals with nitrile rubber (nbr).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Proportional valves and converters turn an electrical signal into pressure or flow without steps. The VP60 series proportional flow and directional control valve Norgren VP6010LJLL1MB200 has a body made of anodised aluminium and covers the temperature range 0 to 60 °C.
Benefits
- High flow rate with low pressure loss
- Calibrated linear flow characteristic with zero crossover
- Instant dynamic response
- Port size G1/4
- Operating pressure -1 to 16 bar
- Flow 1200 l/min
Applications
Typical installations are test benches, coating plants and machine tools.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 120,000,000 cycles.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren VP6010LJLL1MB200 |
| Series | VP60 |
| Valve function | 5/3 |
| Function | APB |
| Valve technology | Glandless spool and sleeve |
| Spool and sleeve | Aluminium |
| Port size | G1/4 |
| Operating pressure | -1 to 16 bar |
| Flow | 1200 l/min |
| Medium | Compressed air |
| Temperature range | 0 to 60 °C |
| Body material | Anodised aluminium |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | M12 x 1 |
| Operating voltage | 21 to 32 V DC |
| Control signal | IO-Link |
| Protection class | IP65 |
| b10 value | 120,000,000 cycles |
| Height | 106.3 mm |
| Width | 50 mm |
| Length | 129.9 mm |
| Weight | 1.25 kg |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | VP6010LJLL1MB200 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Certification | DIN EN ISO 13849 |
