Control block 6/2-way single solenoid G1/8 VOFT-L14-M62-MZT2-G18-1M8RL-APC - Festo 8219319
Control block VOFT-L14-M62-MZT2-G18-1M8RL-APC as a 6/2-way valve (single solenoid) with 770 l/min standard nominal flow rate for controlling pneumatic actuators. Ratings: 0 to 10 bar operating pressure, G1/8 port and 14.5 mm width. Switching times 14 ms on and 65 ms off.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With 770 l/min standard nominal flow rate, the control block VOFT-L14-M62-MZT2-G18-1M8RL-APC switches as a 6/2-way valve (single solenoid) at 0 to 10 bar operating pressure. Further ratings: G1/8 port, 14.5 mm width and 24 V DC operating voltage.
Key benefits
- Flow: 770 l/min standard nominal flow rate at only 14.5 mm width
- Pressure range: 0 to 10 bar
- Switching times: 14 ms on, 65 ms off
- Rugged: IP65 protection, corrosion resistance class 2
- Temperature: -5 to 50 °C ambient
- Continuous duty: 100 % duty cycle
Applications
Mounting: via through-hole for M4 screw. Operating medium for the VOFT-L14-M62-MZT2-G18-1M8RL-APC: compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation not possible.
Technical data
| Type | VOFT-L14-M62-MZT2-G18-1M8RL-APC |
|---|---|
| Festo part number | 8219319 |
| Valve function | 6/2-way valve, single solenoid |
| Type of actuation | electrical |
| Width | 14.5 mm |
| Nominal flow rate standardised according to ISO 8778 | 830 l/min |
| Standard nominal flow rate | 770 l/min |
| pneumatic working port | G1/8 |
| Operating voltage | 24 V DC |
| Operating pressure | 0 to 10 bar |
| Design | piston gate valve |
| Reset method | mechanical spring |
| Degree of protection | IP65 |
| CE mark (see declaration of conformity) | to EU EMC Directive, in accordance with EU RoHS Directive |
| UKCA marking (see declaration of conformity) | to UK RoHS regulations |
| Exhaust-air function | cannot be throttled |
| Sealing principle | soft |
| Mounting position | any |
| Conforms to standard | EN 60947-5-2 |
| Manual override | non-detenting |
| Type of piloting | piloted |
| Pilot air supply | external |
| Flow direction | non-reversible |
| Measuring principle | inductive |
| Overlap | negative overlap |
| Reverse polarity protection | for all electrical connections |
| Reverse polarity protection sensor | for all electrical connections |
| Note on forced dynamization | current information on this topic can be found in Technical Report V |
| Switching position indicator | LED |
| Signal status display | yellow LED, valve control |
| Switching position sensing | normal position with sensor |
| Switching status display sensor | LED |
| Pilot pressure | 3.5 to 8 bar |
| b value | 0.42 |
| C value | 3 l/sbar |
| Switching time off | 65 ms |
| Switching time on | 14 ms |
| Valve - sensor switching time on | 11 ms |
| Valve - sensor switching time off | 70 ms |
| Operational voltage range DC | 24 V |
| Duty cycle | 100% |
| Max. positive test pulse with 0 signal | 800 µs |
| Max. negative test pulse with 1 signal | 400 µs |
| Nominal operating voltage DC | 24 V |
| Permissible voltage fluctuations | -10 % |
| Operating medium | compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | lubricated operation not possible |
| Vibration resistance | transport application test with severity level 2 to FN 942017-4 and EN 60068-2-6 |
| Shock resistance | shock test with severity level 2 to FN 942017-5 and EN 60068-2-27 |
| Corrosion resistance class CRC | 2 - Moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364-Zone III |
| Cleanroom suitability, measured according to ISO 14644-14 | class 5 according to ISO 14644-1 |
| Storage temperature | -10 to 60 °C |
| Media temperature | -5 to 50 °C |
| Sound pressure level | 64 dB(A) |
| Protection against direct and indirect contact | PELV |
| Pilot medium | compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -5 to 50 °C |
| Nominal altitude of use | 1000 m in accordance with VDE 0580 |
| Product weight | 140 g |
| Operating voltage range, DC sensor | 10 to 30 V |
| Short-circuit strength sensor | ja |
| Idle current sensor | 10 mA |
| Max. output current sensor | 200 mA |
| Max. switching frequency sensor | 5000 Hz |
| Residual ripple sensor | ± 10 % |
| Voltage drop sensor | 2 V |
| Electrical connection | 3-pin, M8x1 A-encoded to EN 61076-2-104, plug |
| Sensor connection | cable, 3-pin, 2.5 m |
| Type of mounting | via through-hole for M4 screw |
| Pilot air port 14 | M5 |
| Pneumatic connection, port 1 | G1/8 |
| Pneumatic connection, port 2 | G1/8 |
| Pneumatic connection, port 3 | G1/8 |
| Pneumatic connection, port 4 | G1/8 |
| Pneumatic connection, port 5 | G1/8 |
| Pneumatic connection, port 6 | G1/8 |
| Note on materials | RoHS compliant |
| Material seals | FPM, HNBR, NBR |
| Material housing | wrought aluminium alloy |
| Material cable sheath | PVC |
| Material screws | steel, chemically nickel-plated |
| Switching element function | N/C contact |
| Weight (shipping) | 0.14 kg |
| Weight | 0.14 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VOFT-L14-M62-MZT2-G18-1M8RL-APC |
| EAN | 4052568903077 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/8 |
| Medium | Compressed air |
| Flow rate [l/min] | 770 |
| Actuation type | Electrical |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/8 |
| Protection rating | IP65 |
