Pneumatic valve 3/2-way open/closed 1/8 NPT VL/O-3-1/8-B-NPT - Festo 10840
Festo type VL/O-3-1/8-B-NPT switches one working port as a 3/2-way valve with open/closed function. Key data: 1/8 NPT ports, a standard nominal flow rate of 500 l/min and an operating pressure of -0.95 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The pneumatic valve VL/O-3-1/8-B-NPT switches one working port as a 3/2-way valve with open/closed function. It achieves a standard nominal flow rate of 500 l/min and an operating pressure of -0.95 to 10 bar.
Benefits
- 1/8 NPT ports with width 26 mm, grid dimension 27 mm
- Standard nominal flow rate 500 l/min at nominal size 5 mm
- Operating pressure -0.95 to 10 bar, pilot pressure 1 to 10 bar
- Switching time 4 ms on, 10 ms off, switching frequency up to 12 Hz
- Corrosion resistance class CRC 1, LABS (PWIS) conformity VDMA24364-B2-L
Applications
The VL/O-3-1/8-B-NPT suits single-acting cylinders, blow-off air and pneumatic pilot signals. The VL/O-3-1/8-B-NPT is mounted on manifold rail, with through-hole. Operating medium: compressed air to ISO 8573-1:2010 [7:4:4]. Lubricated operation is possible but must then continue.
Technical data
| Feature | Value |
|---|---|
| Type | VL/O-3-1/8-B-NPT |
| Valve function | 3/2-way, open/closed, monostable |
| Type of actuation | Pneumatic |
| Construction width | 26 mm |
| Standard nominal flow rate | 500 l/min |
| Pneumatic working port | 1/8 NPT |
| Operating pressure | -0.95 to 10 bar |
| Design | Poppet seat |
| Type of reset | Mechanical spring |
| Nominal size | 5 mm |
| Grid dimension | 27 mm |
| Exhaust-air function | Can be throttled |
| Sealing principle | Soft |
| Mounting position | Any |
| Type of piloting | Direct |
| Pilot air supply | External |
| Flow direction | Reversible |
| Spool overlap | Negative overlap (underlap) |
| Pilot pressure | 1 to 10 bar |
| Maximum switching frequency | 12 Hz |
| Switching time off | 10 ms |
| Switching time on | 4 ms |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Note on operating and pilot medium | Lubricated operation possible (lubrication then required for further operation) |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -20 to 60 °C |
| Media temperature | -10 to 60 °C |
| Pilot medium | Compressed air to ISO 8573-1:2010 [7:4:4] |
| Ambient temperature | -10 to 60 °C |
| Product weight | 150 g |
| Type of mounting | On manifold rail, with through-hole |
| Pilot air port 110 | 1/8 NPT |
| Pilot air port 12 | 1/8 NPT |
| Pneumatic connection, port 1 | 1/8 NPT |
| Pneumatic connection, port 11 | 1/8 NPT |
| Pneumatic connection, port 2 | 1/8 NPT |
| Pneumatic connection, port 3 | 1/8 NPT |
| Pneumatic connection, port 33 | 1/8 NPT |
| Note on materials | RoHS compliant |
| Material seals | NBR |
| Material housing | Die-cast aluminium |
| Weight | 0.15 kg |
| Manufacturer | Festo |
| Hersteller-Nr | VL/O-3-1/8-B-NPT |
| EAN | 4052568303655 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Thread | NPT 1/8 |
| Nominal size DN [mm] | 5 |
| Seal material | NBR |
| Medium | Compressed air |
| Function | 3/2 open/closed monostable |
| Flow rate [l/min] | 500 |
| Actuation type | pneumatic |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/8 |
| Temperature (max.) | 60 |
