Union 330, flat sealing, galvanised malleable iron, Rp 1/4 to Rp 2 1/2 - Riegler
The union 330 is a detachable pipe joint that can be separated without turning the pipes. Galvanised malleable iron, service temperature -20 to 200 °C. The variants differ in thread size from Rp 1/4 to Rp 2 1/2. Design to DIN EN 10242.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The union 330 is a detachable pipe joint that can be separated without turning the pipes. The variants differ in thread size from Rp 1/4 to Rp 2 1/2. Maximum temperature and maximum operating pressure must not occur at the same time.
Advantages
- Service temperature -20 to 200 °C
- Dimensions and design to DIN EN 10242
- Whitworth pipe threads to ISO 7-1, compatible with standard pipes and valves
- Material: black malleable iron B350-10, design symbol A
- Hot-dip galvanised, fully coated with pure zinc for rust protection, surface quality to DIN 2444
- Flat sealing with NBR seal
Applications
Used in mechanical engineering, outdoor lines, cold water and heating lines.
Technical data
| Manufacturer | Riegler |
|---|---|
| Design | Union 330, flat sealing |
| Thread 1 | Rp 1/4, 3/8, 1/2, 3/4, 1, 1 1/4, 1 1/2, 2, 2 1/2 female |
| Thread 2 | Rp 1/4, 3/8, 1/2, 3/4, 1, 1 1/4, 1 1/2, 2, 2 1/2 female |
| Thread standard | ISO 7-1 |
| Material | Black malleable iron B350-10, design symbol A |
| Surface | hot-dip galvanised |
| Sealing | flat sealing, NBR seal |
| Temperature range | -20 to 200 °C |
| Note | max. temperature and max. pressure not at the same time |
| Standard | DIN EN 10242, DIN 2444 |
| Type no. of variants | TFV 330-14-D, TFV 330-38-D, TFV 330-12-D, TFV 330-34-D, TFV 330-10-D, TFV 330-114-D, TFV 330-112-D, TFV 330-20-D, TFV 330-212-D |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread type | Internal thread |
| Thread type 2 | Internal thread |
| Norm | DIN EN 10242 |
| Temperature (max.) | 200 |
