Proportional pressure regulator VEAA-B-3-D9-F-V2-1R1 - Festo 8153643

Name: Proportional pressure regulator VEAA-B-3-D9-F-V2-1R1 - Festo 8153643
Brand: Festo
SKU: FES-8153643
Price: 386.26 EUR
Availability: InStock

Festo ✓ Original product Brand new

Net

€386.26

excl. VAT

Item FES-8153643

Manufacturer no. VEAA-B-3-D9-F-V2-1R1

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Technical data

Valve function	3-way proportional pressure regulator
Type of piloting	Direct
Type of reset	Mechanical spring
Type of actuation	Electrical
Mounting position	Any
Sealing principle	Soft
Ambient temperature	0 ... 50 °C
Media temperature	5 ... 50 °C
Storage temperature	-20 ... 70 °C
Dimensions (W x L x H)	15 mm x 61 mm x 66 mm
Pneumatic connection, port 1	Flange
Pneumatic connection, port 2	Flange
Pneumatic connection, port 3	Flange
Material seals	NBR
Type of mounting	With through-hole, With accessories
Inlet pressure 1	0 ... 11 bar
Output pressure 2	0.03 ... 6 bar
Standard nominal flow rate (standardised to DIN 1343)	10 l/min
Standard nominal flow rate 2-3	6 l/min
Linearity	0.5 %FS
Reproducibility	0.4 %FS
Hysteresis	0.25 %FS
Temperature cooefficient	0.05 %/K
Total accuracy	0.75 %FS
Product weight	55 g
Operating medium	Compressed air to ISO 8573-1:2010 [7:4:4], Inert gas
Note on operating and pilot medium	Lubricated operation not possible
Degree of protection	IP65
Approval	RCM
KC mark	KC-EMV
CE mark (see declaration of conformity)	To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)	To UK RoHS instructions
Note on materials	RoHS compliant
LABS (PWIS) conformity	VDMA24364 zone III
Corrosion resistance class CRC	2 - Moderate corrosion stress
Operational voltage range DC	19 ... 29 V
Nominal operating voltage DC	24 V
Residual ripple	10%
Setpoint value	0 - 5 V
Signal range analogue output	1 - 5 V
Accuracy analogue output in ± %FS	2 %FS
Max. electrical power consumption	1 W
Reverse polarity protection	For all electrical connections
Short circuit current rating	For all electrical connections
Safety instructions	Safety position VEAA/VEAB: if the electrical power supply fails, the output pressure is maintained unregulated and may rise or fall – valve blocked.
Display type	LED
Electrical connection	M8x1, Plug, To EN 60947-5-2
Material housing	Reinforced PA
Manufacturer	Festo
Hersteller-Nr	VEAA-B-3-D9-F-V2-1R1
EAN	4052568579814
Zolltarifnummer	84811099
GPSR Herstellerdaten	Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
Artikelzustand	New
Artikel-Authentizität	Original product
