Sub-base G3/8, ISO 5599-1, 48 mm width VABS-S1-1S-G38 - Festo 8032642

Festo ✓ Original product Brand new

The sub-base VABS-S1-1S-G38 connects the mounted valve to the lines of the system. Ports 1, 2, 3, 4 and 5 in G3/8, standard ISO 5599-1, operating pressure -0.9 to 16 bar. Material: die-cast aluminium, CRC 0, RoHS compliant.

Net
€21.66
excl. VAT
Item FES-8032642
Manufacturer no. VABS-S1-1S-G38
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The sub-base VABS-S1-1S-G38 connects the mounted valve to the lines of the system. Pneumatic layout: ports 1, 2, 3, 4 and 5 in G3/8 and pilot air 12/14 in G1/8. The VABS-S1-1S-G38 operates at -0.9 to 16 bar, so vacuum is also possible. The VABS-S1-1S-G38 is made of die-cast aluminium. Corrosion resistance class 0.

Benefits

  • Width: 48 mm
  • Standard: ISO 5599-1
  • Port thread: G3/8 for supply, working port and exhaust
  • Pressure range: -0.9 to 16 bar, vacuum-capable
  • Material: Die-cast aluminium, CRC 0
  • PWIS-free: VDMA 24364-B1/B2-L

Applications

The VABS-S1-1S-G38 is mounted via through-hole for M5 screw. Suitable for compressed air to ISO 8573-1:2010 [7:4:4], lubricated operation possible (in which case lubricated operation will always be required). Ambient and medium temperature -10 to 60 °C each.

Technical data

TypeVABS-S1-1S-G38
Festo part number8032642
Width48 mm
Exhaust-air functionCan be throttled
Based on standardISO 5599-1
Max. number of valve positions1
Operating pressure-0.9 to 16 bar
Pilot pressure0 to 16 bar
Suitability for vacuumYes
Operating mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Note on operating and pilot mediumLubricated operation possible (in which case lubricated operation will always be required)
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Storage temperature-20 to 60 °C
Medium temperature-10 to 60 °C
Pilot mediumCompressed air to ISO 8573-1:2010 [7:4:4]
Ambient temperature-10 to 60 °C
Product weight230 g
Type of mountingVia through-hole for M5 screw
Pilot air port 12/14G1/8
Pneumatic connection, port 1G3/8
Pneumatic connection, port 2G3/8
Pneumatic connection, port 3G3/8
Pneumatic connection, port 4G3/8
Pneumatic connection, port 5G3/8
Note on materialsRoHS compliant
Material sub-baseDie-cast aluminium
Weight0.24 kg
ManufacturerFesto
Hersteller-NrVABS-S1-1S-G38
EAN4052568428662
Zolltarifnummer84819000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialDie-cast aluminium
ThreadG 3/8
MediumCompressed air
NormISO 5599-1
SeriesVABS
Betriebsdruck max [bar]16
Pneumatic connectionG3/8
Temperaturbereich-10-60 °C
Temperature (max.)60
