Sub-base M6, PEEK, CRC 0, PWIS-free VABS-K2-12S-20-M6-P - Festo 8140319

Festo ✓ Original product Brand new

The sub-base VABS-K2-12S-20-M6-P carries a valve and provides its pneumatic ports. Size 12, tightening torque 0.33 Nm. Material: PEEK, CRC 0, RoHS compliant.

Net
€54.27
excl. VAT
Item FES-8140319
Manufacturer no. VABS-K2-12S-20-M6-P
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo sub-base VABS-K2-12S-20-M6-P carries a valve and provides its pneumatic ports. Fluid connection: female thread M6. The VABS-K2-12S-20-M6-P is made of PEEK. Corrosion resistance class 0. Size 12.

Benefits

  • Port thread: M6
  • Tightening torque: 0.33 Nm
  • Material: PEEK, CRC 0
  • PWIS-free: VDMA 24364 zone III

Applications

The VABS-K2-12S-20-M6-P is mounted with through-hole, any mounting position. The valve is attached with female thread. Tightening torques: valve mounting max. 0.33 Nm and max. tightening torque 0.6 Nm. Suitable for liquid and gaseous media, observe resistance of materials that come into contact with the media. Ambient and medium temperature 0 to 50 °C each. Design: connection direction on the side.

Technical data

TypeVABS-K2-12S-20-M6-P
Festo part number8140319
Size12
Nominal size2 mm
Fluid connectionFemale thread M6
Mounting positionAny
DesignConnection direction on the side
Max. number of valve positions1
Flow directionNon-reversible
Operating mediumLiquid media, gaseous media
Note on operating and pilot mediumObserve resistance of materials that come into contact with the media
Corrosion resistance class CRC0 - No corrosion stress
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-20 to 70 °C
Medium temperature0 to 50 °C
Ambient temperature0 to 50 °C
Max. tightening torque for valve mounting0.33 Nm
Max. tightening torque0.6 Nm
Product weight8 g
Mounting type sub-baseWith through-hole
Mounting type valveWith female thread
Note on materialsRoHS compliant
Material sub-basePEEK
Weight0.012 kg
ManufacturerFesto
Hersteller-NrVABS-K2-12S-20-M6-P
EAN4052568567477
Zolltarifnummer84819000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadM6
Nominal size DN [mm]2
SeriesVABS
Pneumatic connectionM6
Temperaturbereich0-50 °C
Temperature (max.)50
