Manifold block for 5 valves, 32 mm grid, 1/2 NPT VABM-B10-30S-N12-5-P3 - Festo 8026425

Festo ✓ Original product Brand new

Groups 5 valves on a 32 mm grid with one shared compressed-air supply. Supply port 1 in 1/2 NPT and exhaust port 3 in 1/2 NPT. Type VABM-B10-30S-N12-5-P3 in wrought aluminium alloy, CRC 2.

Net
€120.16
excl. VAT
Item FES-8026425
Manufacturer no. VABM-B10-30S-N12-5-P3
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The manifold block VABM-B10-30S-N12-5-P3 carries 5 valves on a 32 mm grid and supplies them with compressed air from one source. Ports: supply port 1 in 1/2 NPT and exhaust port 3 in 1/2 NPT. Wrought aluminium alloy, CRC 2 and PWIS conformity to VDMA 24364-B1/B2-L characterise the VABM-B10-30S-N12-5-P3.

Benefits

  • Valve positions: 5 positions on a 32 mm grid
  • Supply: Port 1 in 1/2 NPT, exhaust in 1/2 NPT
  • Material: Wrought aluminium alloy, CRC 2
  • PWIS-free: VDMA 24364-B1/B2-L

Applications

The VABM-B10-30S-N12-5-P3 is mounted with through-hole, in any position.

Technical data

TypeVABM-B10-30S-N12-5-P3
Festo part number8026425
Grid dimension32 mm
Mounting positionAny
Maximum number of valve positions5
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Product weight1313 g
Type of mountingWith through-hole
Pneumatic connection, port 11/2 NPT
Pneumatic connection, port 31/2 NPT
Note on materialsRoHS compliant
Material manifold railWrought aluminium alloy
ManufacturerFesto
Hersteller-NrVABM-B10-30S-N12-5-P3
EAN4052568428150
Zolltarifnummer84819000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadNPT 1/2
Anzahl Stationen [Stk]5
SeriesVABM
Pneumatic connectionNPT 1/2
