Common supply manifold for 8 valves, 27.5 mm grid, G1/2 VABM-B10-25-G12-8-P53 - Festo 8026225

Festo ✓ Original product Brand new

8 valve positions on a 27.5 mm grid save individual tubing, the supply runs centrally through the rail. Supply port 1 in G1/2. Type VABM-B10-25-G12-8-P53 in wrought aluminium alloy, CRC 2.

Net
€82.40
excl. VAT
Item FES-8026225
Manufacturer no. VABM-B10-25-G12-8-P53
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The common supply manifold VABM-B10-25-G12-8-P53 carries 8 valves on a 27.5 mm grid and supplies them with compressed air from one source. Pneumatic layout: supply port 1 in G1/2. The VABM-B10-25-G12-8-P53 is made of wrought aluminium alloy, corrosion resistance class 2, VDMA 24364-B1/B2-L.

Benefits

  • Valve positions: 8 positions on a 27.5 mm grid
  • Supply: Port 1 in G1/2
  • Material: Wrought aluminium alloy, CRC 2
  • PWIS-free: VDMA 24364-B1/B2-L

Applications

The VABM-B10-25-G12-8-P53 is mounted with mounting bracket, in any position.

Technical data

TypeVABM-B10-25-G12-8-P53
Festo part number8026225
Grid dimension27.5 mm
Mounting positionAny
Maximum number of valve positions8
Corrosion resistance class CRC2 - Moderate corrosion stress
LABS (PWIS) conformityVDMA24364-B1/B2-L
Product weight750 g
Type of mountingWith mounting bracket
Pneumatic connection, port 1G1/2
Note on materialsRoHS compliant
Material manifold railWrought aluminium alloy
ManufacturerFesto
Hersteller-NrVABM-B10-25-G12-8-P53
EAN4052568279264
Zolltarifnummer84819000
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/2
Anzahl Stationen [Stk]8
SeriesVABM
Pneumatic connectionG1/2
