Connector, port 1/8 NPT, for Festo valve terminals VABD-B14-P1-N18 - Festo 8099629
The Festo connector VABD-B14-P1-N18 connects components in the valve assembly pneumatically. Key data: port 1 1/8 NPT, operating pressure 1.5 to 10 bar, ambient temperature -20 to 60 °C, sub-base material wrought aluminium alloy.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Port 1 1/8 NPT, Festo part number 8099629. The Festo connector VABD-B14-P1-N18 connects components in the valve assembly pneumatically.
Benefits
- Ports: port 1 1/8 NPT.
- Operating pressure 1.5 to 10 bar for the VABD-B14-P1-N18 as per Festo data sheet.
- VABD-B14-P1-N18 made of wrought aluminium alloy: corrosion resistance class CRC 2.
- LABS (PWIS) VDMA24364 zone III: rating for paint-wetting impairment substances.
Application
For building Festo valve terminals. The VABD-B14-P1-N18 is designed for compressed air to ISO 8573-1:2010 [7:-:-], permissible ambient temperature -20 to 60 °C.
Technical data
| Type | VABD-B14-P1-N18 |
|---|---|
| Festo part number | 8099629 |
| Mounting position | Any |
| Operating pressure | 1.5 to 10 bar |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Corrosion resistance class CRC | 2 - moderate corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 to 60 °C |
| Medium temperature | -20 to 60 °C |
| Ambient temperature | -20 to 60 °C |
| Product weight | 26 g |
| Mounting type | With through-hole |
| Pneumatic connection 1 | 1/8 NPT |
| Note on materials | RoHS compliant |
| Sub-base material | Wrought aluminium alloy |
| Manufacturer | Festo |
| Hersteller-Nr | VABD-B14-P1-N18 |
| EAN | 4052568465933 |
| Zolltarifnummer | 84819000 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | Aluminium |
| Medium | Compressed air |
| Series | VABD |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | NPT 1/8 |
| Temperaturbereich | -20-60 °C |
| Temperature (max.) | 60 |
