V05 series direct acting solenoid valve, G1/4, 2/2, NC, solenoid with spring return - Norgren V05B286N-B432A
Can be exchanged quickly during service. The V05 series direct acting solenoid valve Norgren V05B286N-B432A is designed for port G1/4 and has a body made of polyamide (pa).
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Directional valves control the air path to cylinders, grippers and actuators. The V05 series direct acting solenoid valve Norgren V05B286N-B432A weighs 0.32 kg and has a body made of polyamide (pa).
Benefits
- Compact installation
- Removable coil
- Standard exhaust diffuser
- Port size G1/4
- Operating pressure 0 to 13 bar
- Flow 260 l/min
Applications
The valve is used in assembly, packaging and handling systems and in valve islands.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with sealed plug.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren V05B286N-B432A |
| Series | V05 |
| Product line | Excel 32 |
| Valve function | 2/2 |
| Function | NC |
| Actuation | Solenoid pilot / spring return |
| Valve technology | Poppet |
| Mounting | Inline |
| Port size | G1/4 |
| Operating pressure | 0 to 13 bar |
| Flow | 260 l/min |
| Medium | Compressed air |
| Temperature range | -20 to 50 °C |
| Body material | Polyamide (PA) |
| Seal material | Nitrile rubber (NBR) |
| Electrical connection | DIN EN 175301-803 form A, 30 mm |
| Operating voltage | 12 V DC |
| Power consumption | 9 W |
| Coil code | V05X286A-Q1232 |
| Protection class | IP65 with sealed plug |
| Height | 72.3 mm |
| Width | 52.5 mm |
| Length | 32 mm |
| Weight | 0.32 kg |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | V05B286N-B432A |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | DIN EN 175301-803 |
