V05 series direct acting solenoid valve, flange interface, 2/2, NC - Norgren V05X286M-B638A

Images are examples, some edited with AI. The technical data are authoritative. AI notice

V05 series direct acting solenoid valve, flange interface, 2/2, NC - Norgren V05X286M-B638A

Norgren ✓ Original product Brand new

Switches compressed air reliably and without lubrication. The V05 series direct acting solenoid valve Norgren V05X286M-B638A runs on an operating voltage of 110/120 V AC and has a body made of polyamide (pa).

Net
€157.48
excl. VAT
Item NRG-V05X286M-B638A
Manufacturer no. V05X286M-B638A
Save Compare
Question about this item
Datasheet (PDF)
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Directional valves control the air path to cylinders, grippers and actuators. The V05 series direct acting solenoid valve Norgren V05X286M-B638A covers the temperature range -20 to 50 °C and has a body made of polyamide (pa).

Benefits

  • Compact installation
  • Removable coil
  • Standard exhaust diffuser
  • Port size Flange
  • Operating pressure 0 to 16 bar
  • Flow 150 l/min

Applications

Typical uses are the control of cylinders, grippers and pneumatic tools.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product falls under the WEEE directive. The housing reaches protection class IP65 with sealed plug.

Technical data

PropertyValue
Manufacturer part numberNorgren V05X286M-B638A
SeriesV05
Product lineExcel 32
Valve function2/2
FunctionNC
ActuationSolenoid pilot / spring return
Valve technologyPoppet
MountingSub-base
Port sizeFlange
Operating pressure0 to 16 bar
Flow150 l/min
MediumCompressed air
Temperature range-20 to 50 °C
Body materialPolyamide (PA)
Seal materialNitrile rubber (NBR)
Electrical connectionDIN EN 175301-803 form A, 30 mm
Operating voltage110/120 V AC
Power consumption27/20 VA
Coil codeV05X286A-Q1238
Protection classIP65 with sealed plug
Height67.5 mm
Width52.5 mm
Length32 mm
Weight0.2 kg
Country of originGermany
RoHSCompliant
REACHSVHC substance not present
WEEEWEEE
ManufacturerNorgren
Hersteller-NrV05X286M-B638A
Zolltarifnummer84812090
GPSR HerstellerdatenNorgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
NormDIN EN 175301-803
