Union nut, thread G 3/4", length 13.5 mm, nickel plated brass, width across flats 30 mm

On bulkheads, brackets and stud parts the union nut takes over the locking. The connection is made via the thread G 3/4". The overall length comes to 13.5 mm. The component is made of nickel plated brass.

Benefits

• At 13.5 mm the overall length is defined in the data sheet and can be planned in advance.
• The width across flats of 30 mm takes a standard wrench.
• The hexagon with 6 flats takes a standard wrench and transfers the torque without deformation.
• 1 lock nut secures the setting permanently against loosening caused by vibration.
• Brass can be machined afterwards and stays dimensionally stable on the G 3/4" thread.
• The thread G 3/4" fits the existing port without an adapter.

Technical data

Applications

Locking of stud parts, bulkhead feed throughs, adjustment of valves and sensors. Brass suits drinking water, compressed air and heating lines inside buildings.
