Union nut DN20, G 1", bore 24.3mm, zinc-plated steel, DN 20 mm

Name: Union nut DN20, G 1", bore 24.3mm, zinc-plated steel, DN 20 mm
Brand: Fluidics equipment
SKU: FL-000334
Price: 14.85 EUR
Availability: InStock

Fluidics equipment ✓ Original product Brand new

In daily operation this item connects the hose to a pipe, thread or fitting, and it is supplied as an union nut DN20. The defining values are DN 20 mm and thread G 1".

Net

€14.85

excl. VAT

Item FL-000334

Manufacturer no. 834 2520

Question about this item

Datasheet (PDF)

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

When used as an union nut DN20, the article connects the hose to a pipe, thread or fitting. The data sheet states DN 20 mm as well as thread G 1".

Benefits

profiled shank for a secure seat of the hose, verified by DN 20 mm
thread G 1"
bore diameter 24.3 mm
across flats 41 mm
dimensionally accurate cross section for tight joints

Applications

Typical fields of application are hydraulic and pneumatic lines and in mechanical engineering, rating thread G 1".

Technical data

DN [mm]	20
thread	G 1"
bore diameter [mm]	24.3
across flats [mm]	41
Weight	0.095 kg
Manufacturer	Fluidics equipment
Hersteller-Nr	834 2520
EAN	4050571210656
Zolltarifnummer	73181699
GPSR Herstellerdaten	A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikelzustand	New
Artikel-Authentizität	Original product
Schlüsselweite [mm]	41
