Tie rod cylinder, double acting, 10 inch bore, 1450 mm stroke, G1 - Norgren RM/9100/1450
The stroke can be taken straight into the fixture. Norgren RM/9100/1450 has 1450 mm stroke, port G1 and a temperature range of -20 to 80 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The tie rod cylinder Norgren RM/9100/1450 works double acting at an operating pressure of 1 to 10 bar and guides the piston rod over 1450 mm.
Benefits
- Wide range of bore sizes for many industrial tasks
- Long established and proven design
- Extensive choice of mountings
- Theoretical force 30402 N at 10 inch piston diameter
- Stroke 1450 mm at an operating pressure of 1 to 10 bar
- Barrel made of steel, piston rod made of martensitic stainless steel
Applications
It is built into assembly machines, packaging lines and handling units that need 1450 mm of stroke and a force of 30402 N.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive. The piston seal is made of Nitrile rubber (NBR).
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren RM/9100/1450 |
| Series | RM/900 |
| Operating mode | Double acting |
| Port size | G1 |
| Piston diameter | 10 inch |
| Stroke | 1450 mm |
| Theoretical force at 6 bar | 30402 N |
| Operating pressure | 1 to 10 bar |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adjustable cushioning |
| Piston version | Non-magnetic |
| Cylinder barrel | Steel |
| Piston rod material | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Nitrile rubber (NBR) |
| Piston rod seal | Nitrile rubber (NBR) |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | RM/9100/1450 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
