Tube fitting, tee design, with banjo bolt, thread G 1/8", tube 4.3x3 mm, aluminium, -15 bis +70 °C

The operating pressure reaches from -0.99 bar to 15 bar. The tube fitting connects the male thread G 1/8" and a tube of 4.3x3 mm in doing so. The tee design sets a branch at right angles onto the main line.

Benefits

• Aluminium keeps the weight low and works in the range from -15 °C to +70 °C
• One part serves two outlets and saves additional joints
• The height of 16 mm can be planned into the installation space
• The packaging unit comprises 10 pieces
• Union nut and clamping ring allow the joint to be released repeatedly

Applications

Laboratory equipment and dosing technology, plant construction with frequent modification, tube lines in pneumatics, water lines on machines.
