Tee fitting, with 60° cone, thread G 1/2", PN 350 bar, zinc plated steel

The tee fitting splits a line run or brings two flows together. Zinc plated steel determines the load capacity and the corrosion behaviour. The joint is created via the thread G 1/2". The nominal pressure is stated as 350 bar.

Benefits

• Steel takes the tightening torque on the G 1/2" thread without permanent deformation.
• The nominal pressure of 350 bar defines the load limit of the joint.
• The thread G 1/2" fits the existing port without an adapter.
• 3 ports in one component replace two separate fittings and an intermediate line.
• The branch sits at 90° to the through axis and keeps the flow deflection short.

Applications

Branches and measuring points, distribution to secondary runs, return lines. The zinc plated steel suits hydraulic and compressed air lines in mechanical engineering.
