Push-in fitting, tee design, tube 8 mm, second port 8 mm, nickel plated brass, -20 bis +80 °C

The push-in fitting accepts a tube of 8 mm outside diameter and a second tube of 8 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The temperature range reaches from -20 °C to +80 °C. The tee design sets a branch at right angles onto the main line.

Benefits

• One part serves two outlets and saves additional joints
• The design standard is clearly designated in the data sheet
• The seal in NBR is matched to the range from -20 °C to +80 °C
• The tube is pushed in without tools and released again over the release ring

Technical data

Applications

Workshop distribution and service units, compressed air installation on machines and plants, pneumatic cylinders and valve terminals, control air lines inside the control cabinet.

Standards and conformity

Only silicone free seals and lubricants are used during assembly.
