The push-in fitting saves an intermediate construction because a tube of 10 mm outside diameter and the continuing line meet directly. FDA compliant version, tee design, tube diameter 10 mm.
Push-in fitting, tee design, FDA compliant version, tube 10 mm, POM, FDA compliant
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€5.26
Item
FL-319662
Manufacturer no.
IQST 100 FDA
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.IQST 100 FDA
EAN4050571385248
Customs tariff number39174000
ConditionNew
Artikel
FL-319662
Frequently Bought Together
-
This Item:
€5.26
-
Straight New Line push-in connector, ABC push-in system, tube 8 x 1 mm, M12x1,5
€3.07
-
Cross coupling, tube 25 S (M36x2), stainless steel 1.4571, heavy series
€685.03
Total price
The push-in fitting accepts a tube of 10 mm outside diameter and the continuing line. The part accepts the tube without tools and holds it by the gripping claws. The operating pressure reaches from -0.95 bar to 16 bar. The tee design sets a branch at right angles onto the main line.
Benefits
- One part serves two outlets and saves additional joints
- Approvals to NSF and ANSI 51 as well as 61, KTW, WRC, ACS are documented for the materials
- The seal in NBR is matched to the range from -0.95 bar to 16 bar
- The tube is pushed in without tools and released again over the release ring
Technical data
| Material | POM, FDA compliant |
|---|---|
| Tube outside diameter | 10 mm |
| Operating pressure | -0.95 to 16 bar |
| Design version | FDA compliant version |
| Seal material | NBR |
| Media | lubricated and unlubricated compressed air, non hazardous gases and liquids, water, liquid foodstuffs, mild chemicals |
| Material approvals | NSF and ANSI 51 as well as 61, KTW, WRC, ACS |
Applications
Control air lines inside the control cabinet, workshop distribution and service units, compressed air installation on machines and plants, water and cooling circuits.
Standards and conformity
The following approvals are documented for the materials used: NSF and ANSI 51 as well as 61, KTW, WRC, ACS.
| Weight | 0.014000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | IQST 100 FDA |
| EAN | 4050571385248 |
| Zolltarifnummer | 39174000 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
