Push-in fitting, tee design, tube 10 mm, second port 8 mm, PVDF

This push-in fitting is designed for a tube of 10 mm outside diameter and a second tube of 8 mm outside diameter. The part accepts the tube without tools and holds it by the gripping claws. The material is PVDF, the size is fixed at tube diameter 10 mm. The tee design sets a branch at right angles onto the main line.

Benefits

• One part serves two outlets and saves additional joints
• The transition from 10 mm to 8 mm saves an additional reducer
• Approvals to FDA 21 CFR 177.2600, NSF and ANSI 51 as well as 61 are documented for the materials
• The tube is pushed in without tools and released again over the release ring
• The size 10 is clearly assigned and stays available for reordering

Applications

Pneumatic cylinders and valve terminals, control air lines inside the control cabinet, workshop distribution and service units, compressed air installation on machines and plants.

Standards and conformity

The following approvals are documented for the materials used: FDA 21 CFR 177.2600, NSF and ANSI 51 as well as 61.
