Swivel tube fitting, tee design, thread M 42x2, tube 30 S (M42x2), heavy series S, zinc plated steel

The operating pressure reaches up to 250 bar. The swivel tube fitting connects the male thread M 42x2 and a tube 30 S (M42x2) in doing so. The tee design sets a branch at right angles onto the main line.

Benefits

• Zinc plated steel carries the load of the joint in the range from -40 °C to +120 °C
• The heavy series with the code S follows the dimension series to ISO 8434-1
• One part serves two outlets and saves additional joints
• The cutting ring bites into the tube wall and holds the tube even under pressure surges
• The connection over male thread M 42x2 is fixed in size and needs no adaptor

Applications

Hydraulic lines in machine and plant engineering, pipework on presses and pumps, repair of existing tube fittings, test benches and power unit construction.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
