Cutting ring fitting, tee design, tube 4 LL (M8x1), very light series LL, nickel plated brass

The cutting ring fitting connects a tube 4 LL (M8x1) and the continuing line. The operating pressure reaches up to 100 bar with hard copper tube. The tee design sets a branch at right angles onto the main line.

Benefits

• With tube connection 4 LL (M8x1) the size is fixed, so no reworking of the line is required
• The operating pressure up to 100 bar with hard copper tube is released for this size
• The temperature range from -60 °C to +300 °C covers cold installation and warm machine surroundings
• Nickel plated brass as material covers the released range from -60 °C to +300 °C

Applications

Hydraulic lines in machine and plant engineering, pipework on presses and pumps, repair of existing tube fittings, test benches and power unit construction.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
