Compression fitting, tee design, tube 22 (M30x1.5) mm, brass

The operating pressure reaches up to 54 bar with hard copper tube. The compression fitting connects a tube of 22 (M30x1.5) mm outside diameter and the continuing line in doing so. The tee design sets a branch at right angles onto the main line.

Benefits

• One part serves two outlets and saves additional joints
• The clamping ring can be drawn on safely even on soft copper tube
• With tube diameter 22 (M30x1.5) mm the size is fixed, so no reworking of the line is required
• The operating pressure up to 54 bar with hard copper tube is released for this size
• The temperature range from -60 °C to +300 °C covers cold installation and warm machine surroundings

Technical data

Applications

Copper pipework in plants and buildings, lubrication and cooling lines on machine tools, measuring lines and pressure gauge connections, maintenance of existing pipework.

Standards and conformity

The brass compression fittings cannot be combined with cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
