Super X directional valve, 3/2, G1/8, button / spring return - Norgren 03040402
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
The valve needs no electrical supply and is switched by hand or mechanically. Norgren 03040402 covers function 3/2 at port G1/8 in the temperature range 0 to 70 °C.

Super X directional valve, 3/2, G1/8, button / spring return - Norgren 03040402

NORGREN Original product
Net price (excl. VAT)
€75.21
Item NRG-03040402
Manufacturer no. 03040402
Funktionale Sicherheit · ISO 13849
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.03040402
Customs tariff number84812090
ConditionNew
Add to Wish List Add to Compare
Artikel
NRG-03040402
Frequently Bought Together
Total price

The Super X directional valve Norgren 03040402 switches function 3/2 at port G1/8 at an operating pressure of -0.9 to 10 bar.

Benefits

  • Wide range of operators
  • Suitable for multi-directional flow and dual supply applications
  • High flow capacity
  • Actuation button / spring return
  • Flow 335 l/min at an operating pressure of -0.9 to 10 bar
  • Valve technology softseal spool

Technical data

PropertyValue
Manufacturer part numberNorgren 03040402
SeriesSuper X
Valve function3/2
FunctionNC
ActuationButton / spring return
Valve technologySoftseal spool
Port sizeG1/8
Operating pressure-0.9 to 10 bar
Flow335 l/min
MediumCompressed air
Temperature range0 to 70 °C
Body materialPolyamide (PA)
Seal materialNitrile rubber (NBR)
b10 value1,000,000 cycles
Height21 mm
Width45 mm
Length90 mm
Weight0.07 kg
Country of originCzechia
RoHSCompliant
REACHSVHC substance not present
WEEENon-WEEE

Applications

The valve is used on fixtures, feeding equipment and manual workstations where a signal has to be generated without electricity.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The normal position is NC. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 1,000,000 cycles.

More Information
Weight 0.075000
Manufacturer Norgren
Hersteller-Nr 03040402
Zolltarifnummer 84812090
GPSR Herstellerdaten Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com
Artikelzustand New
Artikel-Authentizität Original product
Certification DIN EN ISO 13849
