Super X directional valve, 3/2, 6 mm PIF, shrouded button / spring return - Norgren 03041532

The Super X directional valve Norgren 03041532 switches function 3/2 at port 6 mm PIF at an operating pressure of -0.9 to 10 bar.

Benefits

• Wide range of operators
• Suitable for multi-directional flow and dual supply applications
• High flow capacity
• Actuation shrouded button / spring return
• Flow 965 l/min at an operating pressure of -0.9 to 10 bar
• Valve technology softseal spool

Technical data

Applications

Typical tasks are end position sensing, release of two-hand controls and the control of cylinders at -0.9 to 10 bar.

Standards and conformity

The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The normal position is NC. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 1,000,000 cycles.
