Operation by shrouded button / spring return makes the valve usable without any electrical supply. Norgren 03041422 switches function 3/2 with 335 l/min of flow.
Super X directional valve, 3/2, 1/8 NPT, shrouded button / spring return - Norgren 03041422
NORGREN
Original product
Net price (excl. VAT)
€109.57
Item
NRG-03041422
Manufacturer no.
03041422
Funktionale Sicherheit · ISO 13849
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.03041422
Customs tariff number84812090
ConditionNew
Artikel
NRG-03041422
Frequently Bought Together
-
This Item:
€109.57
-
5/2-Directional Valve - Norgren 4031430000000000
€474.94
-
5/2-Directional Valve- Mini 18 110VAC - Norgren V415517D-C318A
€166.80
Total price
The Super X directional valve Norgren 03041422 is operated by shrouded button / spring return and releases a flow of 335 l/min at port 1/8 NPT.
Benefits
- Wide range of operators
- Suitable for multi-directional flow and dual supply applications
- High flow capacity
- Actuation shrouded button / spring return
- Flow 335 l/min at an operating pressure of -0.9 to 10 bar
- Temperature range 0 to 70 °C
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren 03041422 |
| Series | Super X |
| Valve function | 3/2 |
| Function | NC |
| Actuation | Shrouded button / spring return |
| Port size | 1/8 NPT |
| Operating pressure | -0.9 to 10 bar |
| Flow | 335 l/min |
| Medium | Compressed air |
| Temperature range | 0 to 70 °C |
| Body material | Polyamide (PA) |
| Seal material | Nitrile rubber (NBR) |
| b10 value | 1,000,000 cycles |
| Country of origin | Czechia |
| RoHS | Compliant |
| REACH | SVHC substance present |
| WEEE | Non-WEEE |
Applications
The valve is used on fixtures, feeding equipment and manual workstations where a signal has to be generated without electricity.
Standards and conformity
The version is RoHS compliant, an SVHC substance is present under REACH. The product does not fall under the WEEE directive. The normal position is NC. For the safety assessment to DIN EN ISO 13849 the manufacturer states a b10 value of 1,000,000 cycles.
| Manufacturer | Norgren |
|---|---|
| Hersteller-Nr | 03041422 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Certification | DIN EN ISO 13849 |
