3/2 directional control valve, NC, air operated, differential pressure, G1/4 - Norgren 03061202
The 3/2 directional control valve with NBR seals switches on a compressed air signal and needs no electrical control. Norgren 03061202 is a 3/2 directional control valve with G1/4 port and rated for -0.9 to 10 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 3/2 directional control valve 03061202 has a G1/4 port and operates from -0.9 to 10 bar. The valve made of zinc alloy delivers a flow of 965 l/min.
Benefits
- Operating pressure -0.9 to 10 bar, so vacuum duty is covered as well
- Flow 965 l/min for fast filling and exhausting
- B10 value 1,000,000 cycles for maintenance planning
- Ambient temperature 0 to 80 °C
Applications
The valve rated -0.9 to 10 bar switches pilot signals and single-acting cylinders.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 03061202 |
| Product type | 3/2 directional control valve |
| Series | Super X |
| Valve function | 3/2 |
| Normal position | Normally closed (NC) |
| Actuation | pressure priority / air pilot |
| Port size | G1/4 |
| Operating pressure | -0.9 to 10 bar |
| Flow | 965 l/min |
| Medium | compressed air |
| Ambient temperature | 0 to 80 °C |
| Body material | zinc alloy |
| Seal material | nitrile rubber (NBR) |
| Spool and sleeve | hard anodised aluminium |
| Valve technology | soft-seal spool |
| Mounting | inline |
| B10 value | 1,000,000 cycles |
| Certificates | DIN EN ISO 13849 |
| RoHS | compliant |
| Hersteller-Nr | 03061202 |
| Zolltarifnummer | 84812090 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Function | 3/2 NC |
| Actuation type | pneumatic |
| Certification | DIN EN ISO 13849 |
| Betriebsdruck max [bar] | 10 |
| Pneumatic connection | G1/4 |
| Temperaturbereich | 0-80 °C |
