Plug-in test point with tube connection 30 S (M42x2), 400 bar, zinc-plated steel - Fluidics equipment
On this plug-in test point with tube connection 30 S (M42x2), the test hose is pushed on instead of screwed, for pressures up to 400 bar. Body in zinc-plated steel, temperature range -20 to +100 °C.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
On this plug-in test point with tube connection 30 S (M42x2), the test hose is pushed on instead of screwed, for pressures up to 400 bar. Taking a reading needs no intervention in the pipework.
Benefits
- Operating pressure up to 400 bar
- Installation in the pipeline via tube connection 30 S, nut thread M42x2
- Test hose is plugged on, not screwed
- Zinc-plated steel for -20 to +100 °C
- Overall height 41 mm
Applications
Used at commissioning, maintenance and troubleshooting on hydraulic and pressure lines.
Technical data
| Feature | Value |
|---|---|
| Product type | plug-in test point |
| Measuring side connection | push-in coupling |
| Tube connection | 30 S (M42x2) |
| Tube OD | 30 mm |
| Series | heavy series |
| Operating pressure | 400 bar |
| Material | zinc-plated steel |
| Temperature range | -20 to +100 °C |
| Overall height | 41 mm |
| Weight | 0.85 kg |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | ME ST 30 S |
| EAN | 4050571487669 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | M 42x2 |
| Tube OD [mm] | 30 |
| Rohrdurchmesser (außen) | 30 S (M42x2) |
| Betriebsdruck max [bar] | 400 |
| Temperaturbereich | -20-100 °C |
| Temperature (max.) | 100 |
Downloads
Questions about this item
Any other question?
Send us the item number and your question. We clarify technical details directly with the manufacturer and usually reply on the next working day.
