Pressure sensor 0 to 6 bar, 2x PNP/NPN, IO-Link SPAU-P6R-T-G18M-L-PNLK-PNVBA-M12U - Festo 604869

Festo ✓ Original product Brand new

Measuring range 0 to 6 bar: the pressure sensor SPAU-P6R-T-G18M-L-PNLK-PNVBA-M12U measures relative pressure and switches via 2 switching outputs, PNP/NPN switchable, plus analogue output 0 to 10 V, 4 to 20 mA or 1 to 5 V. It connects pneumatically via G1/8 port and electrically via M12x1 plug.

Net
€136.72
excl. VAT
Item FES-604869
Manufacturer no. SPAU-P6R-T-G18M-L-PNLK-PNVBA-M12U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Designed for pressures of 0 to 6 bar, the Festo pressure sensor SPAU-P6R-T-G18M-L-PNLK-PNVBA-M12U measures relative pressure and switches via 2 switching outputs, PNP/NPN switchable, plus analogue output 0 to 10 V, 4 to 20 mA or 1 to 5 V.

Benefits

  • Measuring range 0 to 6 bar
  • G1/8 port, electrical: M12x1 plug
  • Analogue output 0 to 10 V, 4 to 20 mA or 1 to 5 V, IO-Link for parameterisation and diagnostics
  • 2 switching outputs, PNP/NPN switchable

Application

Typical tasks include monitoring supply and working pressure on machines and in compressed air networks. Mounting is directly via the thread.

Technical data

TypeSPAU-P6R-T-G18M-L-PNLK-PNVBA-M12U
Pressure measuring range initial value0 bar
Pressure measuring range full scale value6 bar
Type of mountingWith thread
Pneumatic connectionG1/8
Switching output2x PNP or 2x NPN, switchable
Analogue output0 - 10 V, 4 - 20 mA, 1 - 5 V
ProtocolIO-Link
Electrical connection 1, connector systemM12x1
Weight (price list)110 g
Weight0.11 kg
ManufacturerFesto
Hersteller-NrSPAU-P6R-T-G18M-L-PNLK-PNVBA-M12U
Zolltarifnummer85369095
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
ThreadG 1/8
Measuring range max. [bar]6
