Smoothline cylinder (without valve), 63 mm bore, 200 mm stroke - Norgren PRA/822063/M/200
Delivers force and stroke to the fixture without extra mechanics. The Smoothline cylinder (without valve) Norgren PRA/822063/M/200 works at an operating pressure of 1 to 10 bar and is designed for port G1/4.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Pneumatic cylinders create the linear movement in fixtures, feeding and assembly equipment. The Smoothline cylinder (without valve) Norgren PRA/822063/M/200 covers the temperature range -20 to 80 °C and is suitable for compressed air.
Benefits
- Cylinder with smooth semi-cleanline body profile
- Cylinder and mounting conform to ISO 15552
- Additional air ports in the rear end cover
- Port size G1/4
- Operating pressure 1 to 10 bar
- Piston diameter 63 mm
Applications
Typical installations are feeding technology, handling units and fixtures in machine building.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive. The product conforms to ISO 15552.
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren PRA/822063/M/200 |
| Series | PRA/822000/M |
| Product line | IVAC |
| Standard | ISO 15552 |
| Operating mode | Double acting |
| Port size | G1/4 |
| Piston diameter | 63 mm |
| Stroke | 200 mm |
| Theoretical force at 6 bar | 1870 N |
| Operating pressure | 1 to 10 bar |
| Medium | Compressed air |
| Temperature range | -20 to 80 °C |
| Cushioning | Adjustable cushioning |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston rod thread | Male thread |
| Piston seal | Polyurethane (PU) |
| Piston rod seal | Polyurethane (PU) |
| Country of origin | Germany |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
| Manufacturer | Norgren |
| Hersteller-Nr | PRA/822063/M/200 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 15552 |
