Linear drive SLG-12- - - Festo 187855
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Stroke | 100 ... 700 mm |
|---|---|
| Piston diameter | 12 mm |
| Cushioning | Elastic cushioning rings/plates at both ends, Shock absorber, hard characteristic curve |
| Mounting position | Any |
| Guide | Recirculating ball bearing guide |
| Max. number of intermediate positions | 4 |
| Coupling design | Positive-locking (slot) |
| Position detection | Via proximity switch |
| Variants | Pulling |
| Operating pressure | 2 ... 8 bar |
| Mode of operation | Double-acting |
| Operating medium | Compressed air to ISO 8573-1:2010 [7:-:-] |
| Note on operating and pilot medium | Lubricated operation possible (in which case lubricated operation will always be required) |
| Corrosion resistance class CRC | 1 - Low corrosion stress |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Ambient temperature | -10 ... 60 °C |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), return stroke | 68 N |
| Theoretical force at 0.6 MPa (6 bar, 87 psi), advance stroke | 68 N |
| Additional moving mass per 10 mm stroke | 18 g |
| alternative connections | See product drawing |
| Pneumatic connection | M3 |
| Material cover | POM |
| Material seals | TPE-U(PU) |
| Material housing | Aluminium, anodised |
| Weight | 1.4 kg |
| Manufacturer | Festo |
| Hersteller-Nr | SLG-12- - |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
