Signal module for EB 80 valve island, 16 digital terminal block inputs, type 02282S06 - Riegler 150928
This signal module (16 digital terminal block inputs) extends an EB 80 valve island with fieldbus by inputs or outputs right on the island. Connection: 4x connector strip with spring clamping, 12-pin. The type-specific upper part can be replaced without removing other modules.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Inputs and outputs right on the valve island: module 02282S06 is fitted to the left of the electrical fieldbus connection. Remove the aluminium end plate, mount the module with tie rods and refit the plate. The lower part holds the universal transmission electronics, the upper part is the replaceable type-specific section.
Advantages
- 16 digital terminal block inputs, connection 4x connector strip with spring clamping, 12-pin
- Input signal: PNP / NPN (software-configurable)
- Protection: overload and short-circuit protected inputs
- Diagnostics: local via LED light and software message
- Current rating 200 mA per connector, 500 mA per module
- Protection rating IP 65, technopolymer housing
Applications
Automated systems in which valves, signals and pressure control converge on one common island.
Technical data
| Type no. | 02282S06 |
|---|---|
| Seal material | NBR |
| Version | 16 digital terminal block inputs |
| Supply voltage range | 12 -10 % to 24 +30 % V DC |
| Operating voltage | 10.8 to 31.2 V DC |
| Maximum admissible voltage | 32 V DC |
| Input signal | PNP / NPN (software-configurable) |
| Electrical connection | 4x connector strip with spring clamping, 12-pin |
| Ambient temperature | -10 to 50 °C |
| Housing | technopolymer |
| Module type | S |
| Module description | signal module |
| Sensors supply voltage | corresponding to the supply voltage |
| Protection | overload and short-circuit protected inputs |
| Input activity indicator | one LED for each input |
| Diagnostics | local via LED light and software message |
| Diagnostic signals | undervoltage, overvoltage, short-circuit, overload |
| Maximum current per connector | 200 mA |
| Maximum current per module | 500 mA |
| Input impedance | 3.9 kΩ |
| Protection rating | IP 40 |
| Series | EB 80 |
| Weight | 0.24 kg |
| Manufacturer | Riegler |
| Hersteller-Nr | 02282S06 |
| EAN | 4047322814102 |
| Zolltarifnummer | 84818099 |
| GPSR Herstellerdaten | Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Country of Manufacture | Italy |
| Ausführung | 16 digitale Eingänge, Klemmleiste |
| Material | Technopolymer |
| Housing material | Technopolymer |
| Temperaturbereich | -10-50 °C |
| Temperature (max.) | 50 |
