Belongs to assembly on a wall, a panel or a row of units. The connection is made via thread G 1/4". The response pressure covers 1 - 6.5 bar.
Accessory for compressed air equipment, G 1/4", 1 - 6.5 bar, DN 5, brass, dN 5 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€24.32
Item
FL-048178
Manufacturer no.
SV 14-6
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SV 14-6
EAN4050571658878
Customs tariff number84814090
ConditionNew
Artikel
FL-048178
Frequently Bought Together
-
This Item:
€24.32
-
Chemical glycerine filled pressure gauge, vertical version, G 1/2", 100 mm
€165.42
-
Safety relief valve G 1/2", factory set and sealed, DN 11, 37.5 bar, brass
€91.66
Total price
With this accessory for compressed air equipment an arrangement of units can be built up cleanly and extended later. The response pressure extends over 1 - 6.5 bar. The body is made of brass. The device is screwed in with G 1/4". The temperature range extends over -20 to +200 °C.
Benefits
- Nominal width DN 5 in the passage
- Material brass determines strength and resistance of the part
- Released for compressed air and andere ungiftige, non-flammable gases, frei abblasend
- Response pressure 1 - 6.5 bar as the leading rating of the device
- Connection thread G 1/4" for direct installation in the line
- Temperature range -20 to +200 °C for use in the workshop and in the plant
Technical data
| Property | Value |
|---|---|
| DN [mm] | 5 |
| Thread | G 1/4" |
| Response pressure [bar] | 1 - 6.5 |
| Abblasleistung [m³/h] | 1.3 - 4.9 |
| Temperature range [°C] | -20 to +200 |
| Body material | brass |
| Media | compressed air and andere ungiftige, non-flammable gases, frei abblasend |
Applications
Machine and plant construction, mounting of air treatment units, retrofitting and conversion of existing installations.
| Weight | 0.034000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | SV 14-6 |
| EAN | 4050571658878 |
| Zolltarifnummer | 84814090 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Thread | G 1/4 |
| Set pressure [bar] | 1 - 6,5 |
| Abblasleistung [m³/h] | 1,3 - 4,9 |
| Temperaturbereich | -20-200 °C |
