Connection plate for the second solenoid, SF2000 double solenoid and 5/3-way valves on the valve terminal - YPC MSF200

Single solenoid 5/2-way valves have one solenoid and occupy one terminal box station. SF2000 series double solenoid and 5/3-way valves have two, and this connection plate wires the second solenoid into the terminal box. The valve then occupies two stations.

Advantages

• Double solenoid 5/2-way and 5/3-way valves on the same terminal as single solenoid valves
• Controlled at 24 V DC, voltage tolerance ±10 %, power consumption 2.5 W per station
• LED status indicator and protective circuit per station in the terminal box
• Second coil runs through the terminal box and the shared multipole cable, protection class IP 40

Applications

• Double-acting cylinders that hold position on power failure through a double solenoid valve
• Cylinders with mid-position stop through 5/3-way valves on the terminal
• Converting a station from single to double solenoid on an existing SF2000 terminal

Compatibility

For the SF2000 series valve terminal with terminal box with or without jump module. One connection plate is needed per double solenoid or 5/3-way valve. Where vibration occurs, an additional mounting plate holds the coils to the terminal box.
